JL Audio XDM400/4 4 channel amplifier
€649.00
JL Audio XDM400/4
- Condition: New
- Sale type: BTW/21%
- Stock : 2 -4 days extra delivery time
Productinfo:
- 4-channel class D broadband amplifier, 100 W x 4 @ 2 Ω / 75 W x 4 @ 4 Ω - 14.4 V
- This tiny amplifier packs a serious full-range punch, delivering an astonishing 100 watts to each of its four channels in 2 Ω (14.4 V, 1% THD). The breakthrough that allows so much power in such a small package is our NexD ultra-high-speed switching design™, which enables full-bandwidth Class-D operation with ultra-low distortion and outstanding efficiency.
- Use the M400/4 in combination with our M600/1 monoblock to build a 1000W amplifier system to power four satellites and a subwoofer... and fit it all under one seat. Or use the M400/4 on its own to power two satellites and a subwoofer. With the M-Series amplifier, the possibilities are endless.
- The M400/4 features a 12 dB/octave filter for each channel bank, which can be configured as a low-pass or high-pass filter and offers continuous cut-off frequency selection from 50-500 Hz. With the additional HD-RLC remote control (sold separately), the levels of channels 1 and 2 or the overall level of the amplifier can be controlled directly from a remote location.
- This marine amplifier features a white and gray powder coat finish, a sealed cover for the controls and stainless steel hardware for long life in the marine environment.
Service description
- Frequency response 12 Hz - 22 kHz (+0, -1dB)
- Signal-to-noise ratio, based on the highest rated power >104 dB below the rated power (A-weighted, 20 Hz - 20 kHz noise bandwidth)
- Signal-to-noise ratio, relative to 1 W >84 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth)
- Attenuation factor @ 4 Ω >150 / 50 Hz
- Attenuation factor @ 2 Ω >75 / 50 Hz
- THD+N @ Nennleistung <1% @ 2 Ω pro Kanal.
- Input voltage range @ RCA inputs 100 mV - 4 V RMS
- Min. copper power / earthing wire Cross-section 4 AWG wire
- Fuse rating 40 A (AFS, AGU or MaxiFuse™)
Rated continuous power (RMS) @ 14.4 V
- @ 4 Ω 75 W RMS x 4
- @ 2 Ω 100 W RMS x 4
- Bridged @ 4Ω 200 W RMS x 2
Rated continuous power (RMS) @ 12.5 V
- @ 4 Ω 60 W RMS x 4
- @ 2 Ω 90 W RMS x 4
- Bridged @ 4Ω 180 W RMS x 2
Signal processing
- Filter mode(s): Low-pass or high-pass
- Filter slope(s) 12 dB/octave
- Filter frequency range 50 Hz - 500 Hz
- Locked, calibrated filter frequency potentiometers Yes
- Filter defeat function Yes
- Optional remote control (HD-RLC)
- Remote level modes 2 or All channels
- Channel input mode switch Yes (2/4 channels)
- Buffered pass-through preamplifier output
- Selection of the source channel for PreOuts Yes
Dimensions
- Height (H) 52 mm
- Width (B) 216 mm
- Depth (D) 180 mm
