B2 Audio RAGE 8 V3 8 inch subwoofer
€179.00
B2 Audio RAGE 8 V3
- Condition: New
- Sale type: BTW/21%
- Stock : 4-7 days extra delivery time
Productinfo:
- Size: 8 inch
- RMS: 500 Watts
- Peak: 1500 Watts
- Impedance: Dual 4-Ohm
- Voice Coil: 2 inch
- Frequency Response: 10 Hz - 500 Hz
- Sensitivity: 80.6 dB
- Winding Material: Copper
- Magnet Type: Ferrite
- Motor Assembly Weight: 175 Oz
- Cone Material: RNPP
- Surround Type: Tall U Shaped Foam
Thiele Small Parameters
- FS: 42.8 Hz
- Vas: 4.7 L
- RE(series): 6.4 Ohm
- Qms: 5.93
- Qes: 0.59
- Qts: 0.53
- CMS: 90 um/N
- BL^2/RE: 70
- MMS: 153.6 G
- Xmax (one way): 13 mm
- SD: 194.3 cm^2
- Efficiency: 0.07%
- Le(1 KHz): 3.2mH
- EBP: 73
Mounting/Shipping Information
- Overall Diameter: 8.66 in
- Baffle Cutout Diameter: 7.23 in
- Mounting Depth: 5.63 in
- Total Depth: 6.18 in
- Weight: 14.33 lbs
- Enclosure Suggestions
- Sealed: 7.8L/0.274 Ft^3
- Qtc F3: 0.532 / 69.48 Hz
- Ported Compact: 15L / 0.53 Ft^3
- Fb/Port Area/Port Length: 42 Hz/7.98In^2/12"
- Ported: 28L / 0.99Ft^3
- Fb/Port Area/Port Length: 35 Hz/ 7.1In^2/15.8"
- Bandpass 4. Order Ration: 3:1
