Rockford Fosgate POWER 12 inch Subwoofer T1S2-12 / T1S1-12

Rockford Fosgate POWER 12 inch Subwoofer T1S2-12 / T1S1-12
€699.00

ROCKFORD T1S2-12 / T1S1-12



Sale info

  • Condition: New
  • Sale type: BTW/21%
  • Stock : 2 -4 days extra delivery time

Productinfo

  • Carbon fiber/PMI/fiberglass cone with aluminum dust cap
  • Injection-molded foam surround with VAST™
  • Two Nomex progressive sprockets with integrated lead wires
  • Die-cast aluminium frame with integrated cooling fins
  • Custom insulated 6mm² compression spring connections
  • Double-wound 2.5" voice coil with inner/outer windings
  • Encapsulated voice coil to the former coupling technology (to the patent
  • registered)
  • Removable die-cast aluminum trim ring
  • Ventilated pole shoe
  • High Temperature High Energy Neodymium Motor Structure
  • Proprietary split-yoke pass-through motor technology (to the patent
  • registered)
  • Integrated copper cap shorting ring (IDHS)
  • Optional grid insert available
  • Optimized for sealed enclosures

    Specifications:

    • 12" (30cm) flat subwoofer
    • Power handling : 600 watts
    • Max. load capacity : 1200 Watt
    • Voice coil diameter : 3"
    • Magnet weight : 0.41 Kg
    • Cut-out diameter : 285 mm
    • Installation depth : 76.5 mm
    • Woofer displacement : 1.2 liters
    • Delivery weight : 7.3 kg
    • Available in single 1-ohm, or single 2-ohm
    • 2 Ohm variant:
      • Nominal impedance : 2-Ohm
      • Voice coil type : Single voice coil
      • Fs (Hz) : 37
      • Qts : 1.06
      • Qms : 11.22
      • Sd (cm2) : 560
      • Qes :1.17
      • Re (Ohm) : 1.7
      • Vas (liters) : 32.4
      • Xmax (mm) : 15
      • SPL (dB @ 1w/1m) : 85
      • (mH) : 0.45
      • SPL (dB @ 2.8v/1m) : 88
      • Closed cabinet volume (Vb) 31.1 liters
      • Bass reflex cabinet volume (Vb) 56.6 liters
    • 1 Ohm Variant:
      • Nominal impedance 1-ohm
      • Voice coil type Single voice coil
      • Xmax (mm) 15
      • Fs (Hz) 36
      • Qes 1:17
      • Qts 1.06
      • Qms 11.22
      • Sd (cm2) 560
      • Re(Ohm) 0.9
      • Le (mH) 0.31
      • Vas (liters) 32.4
      • SPL (dB @ 1w/1m) 85
      • SPL (dB @ 2.8v/1m) 88
      • Closed cabinet volume (Vb) 31.1 liters
      • Bass reflex cabinet volume (Vb) 56.6 liters

    Download Datasheet
