JL Audio 10TW1-2 10 inch subwoofer
€369.00
JL Audio 10TW1-2
- Condition: New
- Sale type: BTW/21%
- Stock : 2 -4 days extra delivery time
Productinfo ( 2ohm )
- Continuous power handling (RMS) : 300 W
- Recommended amplifier power (RMS) : 75 - 300 W
- Nominal impedance (Znom) : 2 Ω
- Free air resonance frequency (Fs) : 41.45 Hz
- Electrical "Q" (Qes) : 0.696
- Mechanical "Q" (Qms) : 9.7
- Total quality "Q" (Qts) : 0.649
- Equivalent volume (Vas) : 0.364 cu ft / 10.31 L
- One-way linear excursion (Xmax) : 0.40 inch/10.0 mm
- Efficiency (1 W / 1 m) : 82.5 dB SPL
- Diaphragm area (Sd) : 0.0268 square meters
- DC resistance (Re) : 2.428 Ω
Productinfo ( 4ohm )
- Continuous power handling (RMS) : 300 W
- Recommended amplifier power (RMS) : 75 - 300 W
- Nominal impedance (Znom) : 4 Ω
- Free Air Resonant Frequency (Fs) : 38.09 Hz
- Electrical "Q" (Qes) : 0.639
- Mechanical "Q" (Qms) : 10.07
- Total quality "Q" (Qts) : 0.601
- Equivalent volume (Vas) : 0.429 cu ft / 12.15 L
- One-way linear excursion (Xmax) : 0.40 inch/10.0 mm
- Efficiency (1 W / 1 m) : 82.2 dB SPL
- Diaphragm area (Sd) : 0.0268 square meters
Dimensions
- Nominal diameter: 250 mm / 10.0 inch
- Overall diameter (A): 264 mm / 10.375 inches
- Installation diameter (B): 230 mm / 9.0625 inches
- Bolt circle diameter (C) : 246 mm (9.7 inch)
- Engine outer diameter (D): 115 mm / 4.54 inches
- Installation depth (E) : 111 mm (4.36 inches)
- Protrusion of the front grille (F) : 22 mm / 0.87 inch
- Volume displacement : 0.047 cu ft / 1.33 L
- Net weight : 10.5 lb / 4.8 kg
