ESX Quantum QM66SP 6 channel DSP
€449.00
ESX Quantum QM66SP
- Condition: New
- Sale type: BTW/21%
- Stock : 2 -3 days extra delivery time
Productinfo:
- 6 x RCA/ RCA input, balanced
- 6 x high level input (via Molex connector)
- 1 x Optical stereo, S/PDIF 192 kHz, 24 bit
- 1 x USB type B for PC software
- 1 x RJ45 for remote control/extension
- 1 x Bluetooth antenna input
- 1 x power input incl. REM OUT and MODE switch input
- DSP chip from Analog Devices™ 32 bit, 294 MHz, Full HD Audio 96 kHz.
- Signal converter from AKM Velvet Sound™ A/D 32 bit, D/A 32 bit
- HP/LP/BP @ 6-48 dB, phase shift, delay correction 0 ~ 20 ms / 0.01 ms steps.
- Up to 248 output EQs, 120 input EQs (PEQ/HSLF/LSLF) +/- 12 dB, 0.5 dB steps)
- Input mixer, subwoofer control, preset auto switch, priority input mode
- Input sensitivity: low level 1~6 V/RMS, high level 1~15 or 15~45 V/RMS
- Signal to Noise Ratio (A-weighted): Analog Input 106 dB, Digital Input 111 dB
- Optical S/PDIF input S/PDIF 192 kHz, 24 bit
- Distortion factor: Analog input < 0.0015%, digital input < 0.0009%
- Integrated Bluetooth® receiver incl. antenna for controlling the DSP via
- app and full HD audio streaming
- Optional RC-DQ (LCD remote control)
- 6 x RCA/RCA @ 6 V RMS
- 104 x 41 x 189 mm
